6 Layer Flex PCB



Rigiflex is one of the leading manufacturers of lightweight, yet high performing flexible printed circuit boards in the US. We provide these circuit boards in different specifications. Our in-depth technical knowledge, and well-equipped facility enable us to assure shortest turnaround times on all types of printed circuit boards including 6 layer flexible printed circuit boards. These circuit boards have six conductive layers that are placed on an extremely flexible substrate.

The PCB is created using a polyimide, which is a thermally stable alternative to FR4 designs. It also helps increase its heat dissipation capability. We provide the PCB with immersion gold surface finishing, which helps increase its surface planarity. Other advantages of availing this surface finish include increased oxidation resistance, and improved usability for contact surfaces that are untreated. These PCBs can be provided with other surface finishing options, including HASL and OSP on request. All these surface finishes help improve the shelf life, as well as durability of these circuit boards.

6 Layer Flex
Model:	flex board-6L
Layers:	6
Material:	Polyimide
Surface treatment:	immersion gold
Width/space:	4/3 mil
Finish thickness:	0.2mm
Min Hot:	0.3mm

We can provide these circuit boards with board thicknesses 0.5mm~3.0mm (0.02″~0.12″), and copper thicknesses up to 0.5 Oz, 1.0, 2.0, 3.0, 4.0, 5.0 and 6 Oz. The printed circuit board can be availed in maximum panel size 18″x24″, and in solder mask colors such as white, black, green, blue, red, and Taiyo PSR4000 white. The circuit boards can be availed in any of the two popular silkscreen colors – white and black. We employ any of these methods for outline processing – V-cut, punching, and routing.

Rigiflex utilizes thinnest substrates for manufacturing these PCBs. This helps us create narrow lines and streamlined designs. These streamlined designs enable denser device populations, and create complex circuit boards. Also, these circuit boards enable heat dissipation from both its sides. We can design the PCBs with minimal interconnections, which helps reduce the system failures, as well as improve its reliability. The printed circuit boards are vacuum packed, which protects them from shocks during the transportation. This helps us ensure that all our printed circuit boards are delivered in working condition.

OEM Custom Service
Board Thickness	0.5mm~3.0mm (0.02″~0.12″)
Copper thickness:	0.5 OZ, 1.0 OZ, 2.0 OZ, 3.0 OZ, up to 6 OZ
Outline:	Routing, punching, V-Cut
Solder mask:	White/Black/Blue/Green/Red, Taiyo PSR4000 white
Legend/Silkscreen Color:	Black/White
Surface finishing:	Immersion Gold, HASL, OSP
Max Panel size:	18″*24″
Packing:	Vacuum/Plastic bag
Layer:	1 – 20 layers
