Rigid printed circuit boards are the talk of the day. These PCBs are being used in a wide range of applications, owing to the advantages that it offers. Compact design, and production of low electronic noise are the striking features of these circuit boards, which add to their increasing popularity in applications. It is always a good idea to source these PCBs from trusted, and experienced manufacturers. One such manufacturer, which you can trust is Rigiflex. We can help you design and manufacture a 10 layer FR4 rigid printed circuit board with full body gold finish.
Most of our clients prefer gold over other materials as a surface finish option because it offers operational stability, durability, and strength to the printed circuit boards. We use processes, such as electroplating, and immersion for adding gold as a surface finish. . FR4 is used as the base material for manufacturing these PCBs, owing to its beneficial features, such as resistance to fire, good mechanical strength, and an excellent electrical insulation. Thus, these FR4 rigid PCBs with full body gold surface finish are capable of delivering an exceptional performance for several years, with little or no maintenance required.
The 10 layer FR4 rigid PCBs that we manufacture have a board thickness of 1.6 mm, and a copper thickness of 1 OZ. The minimum hole size of these PCBs is 5 mil, whereas the minimum line width is 4 mil. These PCBs do not have silkscreen, but have a green solder mask. Other solder mask color options include black, white, blue, and red. The aspect ratio of these printed circuit boards is 10:1. Other material options for these printed circuit boards, include Nelco, Getek, PTFE, polyimide, CEM3, halogen-free, Rogers, and Teflon.
At Rigiflex, we have a well-equipped facility, which enables us to manufacture high-quality PCBs in different designs specifications and capabilities. The 10 layer FR4 rigid PCBs with full body gold finish are of highest industry standards. Do you have any FR4 rigid PCB requirements? Let us know. We would be happy to help you.
| 10 Layer FR4 Rigid PCB with Full Body Gold | |
| Model: | 10L PCB Board |
| Base Material: | 10L,FR4, TG170 |
| Board Thickness: | 1.6 mm |
| Copper Thickness: | 1OZ |
| Min. Hole Size: | 5mil (0.125mm) |
| Min. Line Width/ Spacing: | 4/5 mil |
| Solder mask/ Silkscreen Color: | Green /No |
| Surface Finishing: | Immersion gold |
| Rigid PCB Capability | |||
| No. | Item | Technical data | |
| 1 | Layer Count | 1-30Layers | |
| 2 | HDI Type | 1+N+1, 2+N+2 | |
| 3 | Material | CEM3, FR-4, Halogen Free, Aluminum-based, Teflon, Rogers, Getek, Nelco, PTFE, Polyimide etc | |
| 4 | Board thickness | 0.2~5.0mm | |
| 5 | Board Size | Max. | 18”x24” |
| Min. | 30x50mm | ||
| 6 | Copper Thickness | Outer layer | 1oz~6oz |
| Inner layer | Hoz~5oz | ||
| 7 | Min. Line Width/Space | 4/4mil(0.1/0.1mm) | |
| 8 | Finished Hole size | Mechanical | 0.20~6.30mm |
| Laser | 5mil, 6mil | ||
| 9 | Blind/buried via(Mechanical) | 0.2mm (min) | |
| 10 | Aspect Ratio | 10:1 | |
| 11 | Hole Dia.Tolerance | PTH | ±0.075mm(3mil) |
| NPTH | ±0.05mm (2mil) | ||
| 12 | Hole Position Tolerance | ±0.05mm (2mil) | |
| 13 | Bow & Twist | ≤0.75% | |
| 14 | Peel strength | 1.4N/mm | |
| 15 | Thermal stress | 288℃ & 20 Sec | |
| 16 | Test Voltage | 50-300V | |
| 17 | Soldermask color | Green, Red, Blue, Black, White | |
| 18 | Silkscreen color | White, Black, Yellow | |
| 19 | Min. S/M Pitch | 4mil(0.1mm) | |
| 20 | Min. Solder Mask Clearance | 0.05mm | |
| 21 | Impedance Control Tolerance | +/-10% | |
| 22 | Outline Tolerance | ±0.10mm (4mil) | |
| 23 | Surface Finish | HASL, Lead free HASL, Immersion Gold/Tin/Silver, OSP, Flash Gold, Gold fingers, Plating Hard Gold, Carbon lnk, Peelable mask | |
